Sony RMT-TX440E - Page 13

13
REAR COVER
4. Unhook left side hooks.
①
Grip the rear cover by hand and use a ruler or jig to remove the hook of the rear
cover back chassis.
②
Flex the rear cover outward to remove the hook. Support set with arm.
1 2
Total rear cover back chassis : 2 hooks
DISASSEMBLY AND REMOVAL CAUTION 43”
