Sony SS-CHPZ7 - Exploded View and Parts List SS-CHPZ7

2
SS-CHPZ7/CHPZ9
EXPLODED VIEW AND PARTS LIST
NOTE:
• -XX, -X mean standardized parts, so they may
have some differences from the original one.
Ref. No. Part No. Description Remarks
1
2
not
supplied
not
supplied
not
supplied
2
not
supplied
1 A-1095-116-A OVERALL ASSY
2 4-874-614-82 SCREW +BV4/3.5
L-CH
SS-CHPZ7
• The mechanical parts with no reference number
in the exploded views are not supplied.
