TYPICAL SYSTEMS
DIMENSIONS
Fixed Mini Dome Series
Video Monitor
DC 12 V/AC 24 V
Power supply
AC outlet
YS-DX504 Multiplexer
HSR-X200/16 or
Time Lapse VCR
Fixed Mini Dome Series
Video Monitor
DC 12 V/AC 24 V
Power supply
AC outlet
HSR-X216/32
Digital Video Recorder
118 (4
3
/4)
117 (4
5
/8)
83.5 (3
3
/8)
2– ø5
50.5 (2)
95 (3
3
/4)
Knockout
Top View
Side View
Rear View
Front View
138 (5
1
/2)
137 (5
1
/2)
83.5 (3
3
/8)
105 (4
1
/4)
60.5 (2
1
/2)
10 (
13
/32)
10 (
13
/32)
2– ø4.5
Threaded for 3/4-inch Conduit
Threaded for 3/4-inch Conduit
Plug Supplied
Top View
Side View
Rear View
Front View
Top View
Side View
Rear View
Front View
121 (4
7
/8)
123 (4
7
/8)
83.5 (3
3
/8)
61 (2
1
/2)
106 (4
1
/4)
2– ø5
Top View
Side View
Rear View
Front View
148 (5
7
/8)
147 (5
7
/8)
85.7 (3
3
/8)
111 (4
3
/8)
65 (2
5
/8)
24.6 (
31
/32)
85.7 (3
3
/8)
24.6 (
31
/32)
4– ø4.5
Threaded for 3/4-inch Conduit
Threaded for 3/4-inch Conduit
Plug Supplied
Multiple Camera Operation
Unit: mm (inches)
Unit: mm (inches)
SSC-CD73V/CD73VT SSC-CD43V/CD43VT
SSC-MD53V SSC-MD33V
