Disassembly
Remove the three Screw M1.6*2.8 by using a screwdriver
with Bits (T5).
Scrap! Not to be reused!
There are ten snap hooks securing the Rear Cover.
Insert a Guitar Pick as shown in picture and gently pull
upwards to release the three hooks of this side.
Do the same to the top side.
To Next Page
