• Waveforms
– DIGITAL Board –
1
IC2006 qh (RMCK)
1 V/DIV, 20 ns/DIV
40.4 ns
2.7 Vp-p
4
IC2006 wj (XMCK)
1 V/DIV, 20 ns/DIV
40.4 ns
2.7 Vp-p
5
IC2006 wk (XOUT)
1 V/DIV, 20 ns/DIV
40.4 ns
2.7 Vp-p
wg
IC3610 tj (X1)
(HDMI 1 mode)
1 V/DIV, 50 ns/DIV
80 ns
2.5 Vp-p
wh
IC3901 wh (OSCOUT)
(HDMI 1 mode)
500 mV/DIV, 10 ns/DIV
22 ns
0.8 Vp-p
wf
IC3604 <zvx (XOUT)
(HDMI 1 mode)
1 V/DIV, 20 ns/DIV
30.2 ns
2.5 Vp-p
e;
IC3511 if (XTALOUT)
(HDMI 1 mode)
1 V/DIV, 20 ns/DIV
35.4 ns
2.6 Vp-p
6
IC2054 <zvc (X-OUT)
1 V/DIV, 50 ns/DIV
79.5 ns
3.1 Vp-p
21 µ s
3.3 Vp-p
3
IC2006 w; (RLRCK)
1 V/DIV, 10 µ s/DIV
22.7 µ s
3.3 Vp-p
wk
IC3901 ra (I2SLRCLK)
(HDMI 1 mode)
1 V/DIV, 10 µ s/DIV
2
IC2006 qj (RBCK)
1 V/DIV, 200 ns/DIV
324 ns
3.3 Vp-p
wj
IC3901 el (I2SSCLK)
(HDMI 1 mode)
1 V/DIV, 200 ns/DIV
354 ns
3.7 Vp-p
wa
IC3604 <zcn (VSYNC_N)
(HDMI 1 mode)
1 V/DIV, 5 ms/DIV
V
3.3 Vp-p
ws
IC3604 <zcj (HSYNC_N)
(HDMI 1 mode)
1 V/DIV, 20 µ s/DIV
H
3.3 Vp-p
wd
IC3604 <zcl (DOTCLK)
(HDMI 1 mode)
1 V/DIV, 20 µ s/DIV
31.8 µ s
3.3 Vp-p
wl
IC3901 rd (I2S0CLK)
(HDMI 1 mode)
1 V/DIV, 50 ns/DIV
88.5 ns
3.4 Vp-p
