62
Chapter 3 Appendix
Connection cable for Thoma TF6 probe
D-sub 15-pin connector (female) Mini DIN 8-pin connector (male)
N.C.
RXD
TXD
N.C.
N.C.
N.C.
GND
N.C.
1
2
3
4
5
6
7
8–15
H SYNC
V SYNC
RTS
GND
N.C.
TXD
+5V
RXD
1
2
3
4
5
6
7
8
18
915
1
2
3
6
8
5
Signal
Pin Number
Pin Number
Signal
Specifications
