Sony Trinitron KV-14MB40 - Page 2

— 2 —
KV-[13M40/50/51], KV-[14MB40/40C/40A], KV-[20M40/S40/S41/V80], KV-[21SE40/40A/40C/80/80A/80C], KV-[21MB40C/40M/40P], KV-[21ME40/40P], KV-[21SB40/40M/40P], KV-21XT4A
KV- 13M40* 14MB40C* 20M40 21MB40M 21MB40C 20V80* 21SE80A 21ME40 21SE40C
13M50** 14MB40A** 20S40 21MB40P 21SB40C 21SE80** 21SE80C 21SE40 21SE40A
13M51** 20S41 21SB40P 21XT4A 21ME40C
14MB40* 21SB40M
Power Requirements 120V, 60 Hz 220V, 50/60 Hz 120V, 60Hz 120V, 60Hz 220V, 50/60Hz 120V, 60Hz 220V, 50/60 Hz 120V, 60 Hz 220V, 50/60Hz
Number of Inputs/Outputs
Video
1)
1*/2** 1*/2** 2 2 2 2 2 2 2
S Video
2)
- - - - - 1*/-** - - -
Audio
3)
1*/2** 1*/2** 2 2 2 2*/** 2 2 2
Audio Out
4)
- - - - - 1*/** 1 - -
Speaker Output (W) 3W 3W 3W (M40) 3W (MB40M/40P) 3W(MB40C) 5W x 2 5W x 2 3W x 2 (ME40) 4W x 2 (SE40A/40C)
3W x 2 (S40/41) 3W x 2 (SB40M/40P) 3W x 2 (SB40C/XT4A) 4W x 2 (SE40) 3W x 2 (ME40C)
Power Consumption (W)
In use (Max.) 75W 80W 80W (M40 ) 80W (MB40M/40P) 85W (MB40C) 100W 105W 90W 95W
90W (S40/41 ) 90W (SB40M/40P) 95W (SB40C)/(XT4A)
In standby 8W 10W 8W 8W 10W 8W 10W 8W 10W
Dimensions (W/H/D) 358 x 342 358 x 342 522 x 477 522 x 477 522 x 477 556 x 464.5 556 x 464.5 610 x 464.5 610 x 464.5
(mm) x 401 mm x 401 mm x 479 mm x 479 mm x 479 mm x 474.9 mm x 474.9 mm x 469..5 mm x 469..5 mm
(in.)
14
1/8
x 13
1/2
14
1/8
x 13
1/2
21 x 18
3/4
21 x 18
3/4
21 x 18
3/4
21
7/8
x 18
1/4
21
7/8
x 18
1/4
24 x 18 24 x 18
x 15
3/4 in.
x 15
3/4 in.
x 18
7/8
x 18
7/8
x 18
7/8
x 18
2/3
in. x 18
2/3
in. x 18
1/2
in. x 18
1/2
in.
Mass
(kg) 10 kg 10 kg 21.6 kg 21.6 kg 21.6 kg 22.6 kg 22.6 kg 20.6 kg 20.6 kg
(lbs) 22 lbs. 22 lbs. 48 lbs. 48 lbs. 48 lbs. 49 lbs. 3 oz. 49 lbs. 3 oz. 45 lbs. 45 lbs.
Television System
1)
1 Vp-p 75 ohms unbalanced, sync negative ( )
 SRS (SOUND RETRIEVAL SYSTEM)
American TV Standard (all models except: KV-14MB40A/21SE40A/21XTA4/21SE80A)
2)
Y: 1 Vp-p 75 ohms unbalanced, sync negative The ( ) SRS (SOUND RETRIEVAL SYSTEM) is
PAL-M, PAL-N, NTSC (for KV-14MB40A/21SE40A/21XTA4/21SE80A only) C: 0.286 Vp-p (Burst signal), 75 ohms manufactured by Sony Corporation under license
3)
500 mVrms (100% modulation), Impedance: 47 kilohms from SRS Labs, Inc. It is covered by U.S. Patent No.
Channel Coverage
4)
More than 408 mVrms at the maximum volume setting (variable) 4,748,669. Other U.S. and foreign patents pending.
VHF: 2-13 / UHF: 14-69 / CATV: 1-125 More than 408 mVrms (fix) The word 'SRS' and the SRS symbol ( ) are
Picture Tube Impedance: 50 kilohms registered trademarks of SRS Labs, Inc.
Trinitron Tube
Design and specifications are subject to change
Licensed by BBE Sound, Inc. under
Visible Screen Size
without notice.
USP 4638258.4482866. BBE and BBE symbol are
13-inch picture measured diagonally trademarks of BBE Sound, Inc.
20-inch picture measured diagonally
Actual Screen Size (For KV-21SE80/21SE80A/21SE80C/20V80 only)
14-inch picture measured diagonally
21-inch picture measured diagonally
Antenna
75 ohm external terminal for VHF/UHF
Supplied Accessories
Remote commander (w/2 size AA (R6) batteries)
RM-Y156: (KV-13M40/13M50/14MB40/20M40/21MB40M/
21MB40P/21MB40C/14MB40C/14MB40A/21ME40/21ME40C only)
RM-156W: (KV-13M51/20S41 only)
RM-Y155: (KV-20S40/21SB40M/21SB40P)
21SB40C/21XT4A/21SE40/21SE40C/21SE40A only)
RM-Y135A: (KV-20V80/21SE80/21SE80A/21SE80C only)
Antenna Dipole (7 models)
(KV-21SE80A/21SE40A/21XT4A/13M40/13M50/13M51/14MB40A only)
Antenna Connector
(all models except: KV-20M40/20S40/20S41/21SE80/21SE80C/20V80)
Optional Accessory
Antenna dipole (KV-20M40/20S40/20S41 only)
SPECIFICATIONS
