Sony XR-65A80L Service Manual

Title Page
SAFETY NOTES
4
SELF DIAGNOSIS FUNCTION
12
TROUBLESHOOTING
15
SOFTWARE UPDATE & RESET
143
DIAGRAMS
146
HANDLING GUIDE
155
TABLE OF CONTENTS
Note: Pictures provided in this manual may have difference from actual sets
Please refer Service Manual (Disassembly) for below information:
 Tools and Equipments
 FFC Precautions
 Disassembly and Removal Caution
 Wire Dressing
 Circuit Board Location
 Exploded Views and Part Lists
 Smart Core
 Appendix - Sharp Edge
- FFC Replacement Cautions
SYSSET
2023/11/2806:39:49(GMT+09:00)

Sony XR-65A80L Specifications

General

AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy saving mode	Yes
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	460 W
Screen shape	Flat
Response time	- ms
Display diagonal	65 \
Display brightness	- cd/m²
Display technology	OLED
Native aspect ratio	16:9
Contrast ratio (typical)	-
Display diagonal (metric)	164 cm
Supported graphics resolutions	3840 x 2160
Tuner type	Analog & digital
Supported TV bands	VHF, UHF
Analog signal format system	PAL, SECAM
Digital signal format system	DVB-T2, DVB-S, DVB-C, DVB-S2, DVB-T
Music apps	Classic FM, Spotify, YouTube Music
Video apps	4oD, All 4, Amazon Prime Video, Apple TV, DAZN, Disney+, Freeview Play, Google TV, ITV Hub, My5, Rakuten TV, Vimeo, YouTube
Smart modes	Cinema, Custom, Dolby Vision Bright, Dolby Vision Dark, Game, Graphics, IMAX Enhanced, Netflix Calibrated, Photo, Standard, Vivid
Sports apps	BT Sport
Lifestyle apps	Facebook, Google Apps, Skype
Operating system version	Android 10
App distribution platform	Google Play
Operating system installed	Android
Sound modes	Cinema, Dialog, Dolby Audio, Music, Sports, Standard
Audio decoders	Dolby Atmos
RMS rated power	50 W
Number of speakers	5
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Bluetooth profiles	A2DP, HID, HOGP, AVRCP, SPP
Product color	Black
Rollable display	No
Panel mounting interface	300 x 300 mm
Picture processing technology	Sony XR Super Resolution, Sony XR Triluminos Pro, Sony XR HDR Remaster, Sony XR Smoothing
High Dynamic Range (HDR) technology	Hybrid Log-Gamma (HLG), High Dynamic Range 10 (HDR10), Dolby Vision
Package depth	958 mm
Package width	1574 mm
Package height	180 mm
Package weight	32000 g
Cables included	AC
RF ports quantity	1
HDMI ports quantity	4
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0

Weight and Dimensions

Stand width	1164 mm
Depth (with stand)	327 mm
Height (with stand)	862 mm
Weight (with stand)	24200 g
Depth (without stand)	53 mm
Width (without stand)	1448 mm
Height (without stand)	836 mm
Weight (without stand)	23300 g
