Soosan
H
draulic Breaker
Soosan Heav
Industries Co.
Ltd
■ Removal of the Hydraulic Breaker
When the bucket and breaker operation alternately, the bucket and breaker can be easily exchanged by the
hydraulic hoses and two mounting pins. However there is a risk of hydraulic contamination accordingly, do
installation and removal as follows.
Timber
(1) Move the carrier to stable ground free from mud, dust and dirt.
(2) Place the hydraulic breaker on timber.
(3) Stop the engine, turn off the main switch and deflate air from oil tank if it is
(4) Turn 90° the shut off valve installed to the end of arm to prevent hydraulic from flowing out.
9
0
°
(5) Loosen hose plug on the breaker arm. Collect small amount of oil flowing out at this time and put into
a container.
(6) Be careful to prevent mud or dust from entering oil hoses and pipe lines. Plug oil hoses with hose
plug and pipe lines with union caps. Bind high-and low-pressure hoses with a wire to prevent them
from getting mud.
To Next Page
