4.3 Hydraulic pipe lines for exclusive use
Operation of the hydraulic breaker requires installation of hydraulic pipe lines for exclusive use of the
hydraulic breaker. As hydraulic pipe lines vary depending on base machines, our service engineer must first
check hydraulic pressure, oil capacity, pressure loss and other conditions of the base machine before
installing hydraulic pipe lines. Use only genuine parts in case of replacement because hydraulic pipe
lines(hoses, pipes and fittings) are made of materials carefully selected in consideration of durability.
THE HYDRAULIC SYSTEM TO THE BASE MACHINE MUST BE CHECKED BY AN AUTHORIZED
SOOSAN SERVICE ENGINEER BEFORE FIRST USE AND AFTER ANY MODIFICATIONS.
MAKE SURE THAT THE HYDRAULIC BREAKER VALVE OF HYDRAULIC SYSTEM IS PROPERLY
SET.
RELIEF V/V
GEAR PUMP
O/SWITCH
PILOT V/V
M.C.V
BREAKER
STOP V/V
OUT
MAIN PUMP
IN
W
RNING
WARNING
