3
Other Ports Type Comment
COM RJ45/Micro USB You can connect a serial console to either the RJ45 or micro USB COM
port to access the CLI. Only one port can be used at any time. If both ports
are connected then the micro USB port will take precedence.
The required connection settings are:
Ì Bits per second: 38,400
Ì Data bits: 8
Ì Parity: N (none)
Ì Stop bits: 1
USB USB 3.0 (Type A) You can connect a USB 2.0 or 3.0 compatible device to this
port (e.g. USB thumb drive, UPS, 3G/4G dongles).
MGMT RJ45 (10/100/1000 Mbps) We recommend using this dedicated port to connect your Admin PC.
USB (rear) USB 2.0 (Type A) You can connect a USB 2.0 compatible device to this port (e.g. keyboard).
Module Slots Type Comment
A Flexi Port Can be used for any Flexi Port module listed in the table below
Compatible Modules
*
Comment
8 port GbE copper Flexi Port
8 port GbE SFP Flexi Port
4 port GbE copper – 2 Bypass groups Flexi Port
4 port 10 GbE SFP+ Flexi Port
4 port 2.5 GbE copper PoE Flexi Port
4 port GbE copper PoE + 4 port GbE copper Flexi Port
* SFP/SFP+ transceivers are sold separately
Quick Start Guide XGS 2100/2300/3100/3300
ENGLISH
