SoundCraft CPS2000 User Manual

200V
230V
100V
115V
Mains Voltage Selector Positions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS: RISQUE DE CHOC ELECTRIQUE
- NE PAS OUVRIR
AVIS: RISQUE DE CHOC ELECTRIQUE
- NE PAS OUVRIR
NO USER SERVICEABLE PARTS INSIDE
NO USER SERVICEABLE PARTS INSIDE
NO USER SERVICEABLE PARTS INSIDE
NO USER SERVICEABLE PARTS INSIDE
PIN 1, 2, 3, 4 +17V 16A
PIN 1, 2, 3, 4 +17V 16A
9, 10, 11, 12 -17V 16A
9, 10, 11, 12 -17V 16A
13 +48V
13 +48V
18 +8V
18 +8V
19
NOT USED
NOT USED
1.25A
5, 6, 7, 8 +0V
5, 6, 7, 8 +0V
16, 17 0V
16, 17 0V
0.5A
14, 15 CHASSIS GROUND
14, 15 CHASSIS GROUND
( BOTH DC CONNECTORS HAVE
IDENTICAL PINOUT )
( BOTH DC CONNECTORS HAVE
IDENTICAL
PINOUT )
DC POWER OUT
TO CONSOLE
DC POWER OUT
TO CONSOLE
DC POWER IN
FROM STANDBY SUPPLY
DC POWER IN
FROM STANDBY SUPPLY
TO REDUCE THE RISK
OF FIRE OR ELECTRIC SHOCK
OF FIRE OR ELECTRIC SHOCK
DO NOT EXPOSE THIS UNIT
DO NOT EXPOSE THIS UNIT
TO RAIN OR MOISTURE
DO NOT COVER ANY VENTILATION
DO NOT COVER ANY VENTILATION
SLOTS AS THIS MAY CAUSE THE
SLOTS AS THIS MAY CAUSE THE
EQUIPMENT TO OVERHEAT
EQUIPMENT TO OVERHEAT
WARNING:
MAINS VOLTAGE SELECTION
200V 100V
115V
230V
200V
230V
100V
115V
48V
+
8V
HIGH TEMP
+
17V
CLEAN FAN FILTERS REGULARLY
DO NOT COVER
ANY VENTILATION SLOTS, AS
THIS MAY CAUSE THE EQUIPMENT
TO OVERHEAT
WARNING:
+
17V
-
ACCESS TO MAINS VOLTAGE SELECTION SWITCHES
WARNING: DISPLAY MAINS VOLTAGE SETTING IN
SIDE WINDOW WHEN REFITTING COVER PLATE.
UNDER COVER PLATE.
ENSURE CORRECT MAINS VOLTAGE
SETTING AND CORRECT FUSE BEFORE
CONNECTING MAINS SUPPLY.
DO NOT SWITCH MAINS VOLTAGE SETTINGS
WHILE MAINS SUPPLY IS CONNECTED.
DOTS LIGHT WHEN MAINS LOW
POWER
ON
1
0
OFF
MAINS VOLTAGE
CONSOLE POWER SUPPLY CPS
2 000
MAINS FUSE:
CAUTION:
ATTENTION:
100V/230V USE T10.0A/250V
TO REDUCE THE RISK OF
AFIN DE REDUIRE LE
RISQUE DE FEU, REMPLACER SEULEMENT
AVEC FUSIBLE DE MEME TYPE.
FIRE, REPLACE WITH SAME
TYPE FUSE ONLY.
Front and Rear Panel Views
4 Introduction
