Soundoff Signal UltraLITE EL3H12A20 Series User Manual

WARNING: Warning devices are strictly
regulated and governed by Federal, State and
Municipal ordinances. These devices shall be
used ONLY on approved vehicles. It is the sole
responsibility of the user of these devices to
ensure compliance.
!
WARNING
This product contains high intensity LED devices.
To prevent eye damage, DO NOT stare into light
beam at close range.
PATTERN SELECTION
1. Connect BLACK wire to ground.
2. Connect RED wire to +12VDC.
3. Connect GREEN and BLUE wires to
+12VDC.
4. With power applied to the two wires
momentarily apply power to WHITE wire to
change the directional arrow patterns.
5. While changing patterns, the UltraLITE will
display the left arrow pattern.
6. When you have chosen the directional arrow
pattern, disconnect GREEN and BLUE wires
from power.
7. Connect BROWN wire to +12VDC and
momentarily apply +12VDC to WHITE wire
to change the warning pattern displayed on
the UltraLITE.
8. When you have selected the warning pattern
for the UltraLITE, disconnect BROWN wire
from power.
9. You are finished configuring the UltraLITE.
EL3H12A(xxx) 2.09
END MODULE WARNING
1 Traffic Mover Simultaneous
2 Q-Switch Alternating
3 RoadRunner Alternating
4 Power Pulse Alternating
5 Progressive Alternating
Simultaneous: 1 and 12 together
Alternating: 1 alternates with 12
ARROW PATTERNS for
12 MODULE UltraLITE - EL3H12A10(x) 10+2 COLOR
1 Solid Fast High Power
2 Solid Plus Fast High Power
3 Sequential Fast High Power
4 Sequential2 (2 lights) Fast High Power
5 Chaser Fast High Power
6 Solid Slow High Power
7 Solid Plus Slow High Power
8 Sequential Slow High Power
9 Sequential2 (2 lights) Slow High Power
10 Chaser Slow High Power
11 Solid Fast Low Power
12 Solid Plus Fast Low Power
13 Sequential Fast Low Power
14 Sequential2 (2 lights) Fast Low Power
15 Chaser Fast Low Power
16 Solid Slow Low Power
17 Solid Plus Slow Low Power
18 Sequential Slow Low Power
19 Sequential2 (2 lights) Slow Low Power
20 Chaser Slow Low Power
12 MODULE BAR
DIRECTIONAL ARROW
W/ SINGLE WARNING TIPS
CONFIGURATION INSTRUCTIONS
EL3H12A1Ø(x)
