Soundstream VRCPAA-70M User Manual

FUNCTIONS APPLICATION
EQ: Touch EQ icon to enter below
menu:
: Enter sound focus control
: Fine adjustment
function.
: Fast set sound focus’s control
point.
: Up/down slide to switch
EQ modes: rock/classical/jazz/etc.
: Reset to default settings.
: Set sound delay.
General Setting
Touch To set relevant functions
on/off . More items can be accessed
by sliding the menu.
Brightness : Left and right slide
RDS
icon to adjust screen’s
RDS
brightness.
Touch the icon to set the brightness
and contrast of the screen.
SWC: Touch “SWC” icon to enter
the steering wheel control menu.
wheel control menu.
Radio Area: Choose the required.
radio region.
Serial/Version: Touch the icon to
enter serial number and version
number interface,
to check the needed information.
(Please refer to the actual unit display)
Language: Touch the icon to enter
language setting interface,
Video Control:
8
Surround
Surround
Surround
select the required language.
Reset Factory Data
Once selected, the unit will
prompt to confirm reset to factory
settings. Once confirmed the
system will automatically reboot.
All data will be lsoot and any

Soundstream VRCPAA-70M Specifications

Power

power supply	DC10-16V
current drain	15A
grounding system	Negative Ground

Operating Environment

operating temperature	-20~+60℃

Display

tft screen size	7 inch
resolution	800x480 Pixels

FM Radio

frequency range (usa)	87.5~107.9MHz
frequency range (europe)	87.5~108.0MHz
enable sensitivity (s/n=30db)	≤15dB

AM Radio

frequency range (usa)	530~1710KHz
frequency range (europe)	522~1620KHz
enable sensitivity (s/n=20db)	≤40dB

Weight and Dimensions

dimensions	178mm(W)x168mm(D)x100mm(H)
