Source 1 AC018X1222A - Page 2

Unitary Products Group
2 of 4 035-15826-002 Rev. I (0903)
Models 18, 24, 30, and 36
ITEM DESCRIPTION AC018X1222A AC024X1222A AC030X1222A AC036X1222A
1 Fan Guard 026-35511-018 026-35511-018 026-35511-022 026-35511-022
2 Wireway 028-13215-000 028-13215-000 028-13216-000 028-13216-000
3 Fan Motor 024-26067-010 024-26067-010 024-26029-000 024-27596-000
4 Fan Blade 18” Diameter
Fan Blade 22” Diameter
026-34091-000
---
026-34091-000
---
---
026-34097-000
---
026-34593-000
5 Top 2218-1021/A 2218-1021/A 2260-1021/A 2260-1021/A
6 Outdoor Coil Assembly 373-19800-003 373-19800-003 373-19800-004 373-19800-004
7 Compressor 015-03426-004 015-02748-004 015-03432-004 015-03424-001
8 Compressor Mount (Pkg. of 4) 9435-1081 9435-1081 9435-1081 9435-1081
9 Dual Capacitor (30/5 MFD)
Dual Capacitor (35/5 MFD)
Dual Capacitor (45/5 MFD)
024-24778-000
---
---
024-24778-000
---
---
---
024-23998-000
---
---
---
024-25895-000
10 Contactor (30 amp) 024-27531-000 024-27531-000 024-27531-000 024-27531-000
11 Base Valve 3/4” 025-31900-000 025-31900-000 025-31900-000 025-31900-000
12 Base Valve 3/8” 025-31899-000 025-31899-000 025-31899-000 025-31899-000
13 Filter Drier 029-22156-000 029-22156-000 029-22156-000 029-22156-000
14 Base Pan 2218-1011 2218-1011 2260-1011 2260-1011
15 Control Box Cover 2218-1151/A 2218-1151/A 2218-1151/A 2218-1151/A
16 Ground Lug 025-21798-000 025-21798-000 025-21798-000 025-21798-000
17 Coil Guard 373-20091-009 373-20091-009 373-20091-010 373-20091-010 <
18 Blockoff Plate 2242-1081/B 2242-1081/B 2248-1081/B 2248-1081/B
19 6 Position Plug 025-33306-006 025-33306-006 025-33306-006 025-33306-006
20 Strain Relief 025-09687-000 025-09687-000 025-09687-000 025-09687-000
21
22
23 Coil Guard, Plastic Mesh 028-14727-000 028-14727-000 028-14728-000 028-14728-000
24
25 Start Device, Solid State --- --- --- ---
26
27* Kit, Motor Mounting (Acorn Nuts) 363-90117-000 363-90117-000 363-90117-000 363-90117-000
NOTE: *Not Shown
New replacement parts shown in bold face type at the first printing of parts list dated 9/03.
Major components and suggested stocking items are shown with shaded item number.
“<“ Across from row indicates a change in that row.
--- Not applicable to specified model.
