Page 3
Display Features
Desired Set Temperature
Indicates desired room temperature(s). Also displays the highest
and lowest temperatures for the day.
Occupied & Unoccupied icons
Indicates the program number: Occupied 1,2,3 or Unoccupied.
Override icon
Indicates the program is currently being overridden for up to 4
hours.
Setup Step icon
Indicates the step number when the thermostat is in the
setup mode.
icon
Indicates the keypad has been locked.
Get to Know Your Thermostat
12
12
11
10
Unoccupied123
Override
9
2nd and 3rd Stage icons
Indicates what stage of cooling or heating is currently
energized.
11
10

Source 1 S1-TBSU22HN Specifications

General

Brand	Source 1
Model	S1-TBSU22HN
Category	Thermostat
Language	English
