Rudder
Overview
The rudder consists of the skin, 3 ribs, 4 stiffeners, a hinge half, and the rudder control
horn.
Simple overview
1. Prepare Parts using guidelines HERE
2. Fit rudder control horn to rudder rib 1
3. Fit stiffeners to skin
4. Fit ribs
5. Fixture
6. Fit hinge
7. Up drill
8. Disassemble, debur and dimple as needed
9. Re-assemble and rivet
Detailed Instructions
1. Using plans P-T-VT-rudder details fit the rudder control horn to lower rib (P-T-VT-
R-rib 1). De-bur but do not rivet at this time!
2. Un-cleco the rudder horn from rib 1.
To Next Page
