11
Kit De Rescate A
Distancia Gotcha
14. Sólo después de que el peso de la víctima haya
sidotransferido al GOTCHA™ podrá desconectarse su
cordónde sujeción.
15. Ahora se podrá elevar a la víctima a un punto seguro, o
sepodrá descender de la manera siguiente.
16. Para descender a la víctima, el rescatador debe agarrar
lacuerda que sale del GRIGRI, que utilizará para controlar
eldescenso.
17. Con la otra mano debe soltar la empuñadura negra
delGRIGRI hasta que la cuerda pueda ser alimentada a
unavelocidad controlable. De esta manera se desciende a
una
NOTA: Para llevar a cabo un rescate, el rescatador
necesitará un arnés con punto de enganche delantero
donde colocar el GRIGRI. Si el punto de anclaje del
GOTCHA™ se encuentra de tal manera que sólo se
puede descender a la víctima, entonces la longitud de
la cuerda del kit deberá ser cuatro veces más larga
que la distancia entre el anclaje y el punto seguro.to
the point of safety.
Anclaje a nivel de los pies.
1. Acceda al punto de anclaje de la víctima.
2. Conecte la eslinga de anclaje a un punto de anclaje
adecuado y situado por encima de la víctima.
3. El rescatador utilizará sus piernas para ayudar a tirar de la
cuerda. La polea sencilla se engancha a la eslinga de
anclaje.
4. Ajuste la pértiga a la longitud adecuada.
5. Conecte el clip rojo al extremo de la pértiga y enganche la
polea doble a la cincha.
6. Ajuste las cuerdas entre las poleas para que tengan la
misma longitud que la pértiga.
7. Ponga el clip rojo en posición “abierto”.
8. Utilizando la pértiga, conecte el clip rojo al punto de
enganche del arnés de la victima.
9. Retire la pértiga del clip rojo.
10. Conecte el GRIGRI al arnés del rescatador.
11. Tire de la cuerda sin tensión a través del GRIGRI para
tensionar el sistema y póngase en cuclillas.
12. Ahora el rescatador debe levantarse, elevando así a la
victima.
13. Con una mano, el rescatador sujeta la cuerda por debajo
del GRIGRI, cerca de la eslinga de enganche. Con la
otra mano agarra la cuerda sin tensión mientras se pone
en cuclillas.
14. Sólo después de que el peso de la víctima haya sido
INSTALLATION & USE : INSTRUCTIONS
Anchor more than 1.5m above foot level.
1. Access casualty’s anchorage point.
2. Attach the anchor sling to a suitable anchor point
above the casualty.
3. The rescuers weight is used to assist in the operation.
The double pulley is clipped to the anchor sling.
4. Adjust pole to the required length.
5. Attach the red clip to the end of the pole, and clip the
single pulley into the webbing.
6. Adjust ropes in-between the pulleys to the same length
as the pole.
7. Set the red clip to open.
8. Using the pole, attach the red clip to the casualty’s
harness attachment.
9. Remove the pole from the red clip.
10. Attach the GRIGRI to the rescuers harness.
11. Pull the slack rope through the GRIGRI to tension the
system.
12. The rescuer now sits down, thus raising the casualty.
13. With one hand, the rescuer holds the rope above the
GRIGRI, close to the attachment sling. With the othe
hand they take in the slack rope as they stand up.
14. Once the casualty’s weight has been transferred to the
GOTCHA™, then their lanyard can be disconnected.
15. The casualty can now be raised to a point of safety, o
lowered as follows.
16. To lower the casualty the rescuer must take hold of the
rope that exits the GRIGRI, and this is used to control
the descent.
17. With the other hand releases the black handle on the
GRIGRI until the rope can be fed at a controllable
speed. This thus lowers the casualty.(Please see
note)
16-17
5
7
NOTE: In order to carry out a rescue the rescuer requires a harness with a front point of attachment for locating the GRIGRI.
If the anchor point for the GOTCHA™ is such that the casualty must be lowered, then the rope length in the kit must
be four times the distance from the anchorage to the point of safety.
11-13
8
HIGH
ANCHOR
Blue Pulle
