Green Data
In/Out
Serial data in/out. Look at arrows and
labels on strip to check which it is.
Serial data in/out. Look at arrows and
labels on strip to check which it is.
Yellow GND Ground. 0V. Ground. 0V.
Each of the wire pigtails are terminated by a three-pin JST SM connector, which you can use to connect string
strips together. For the first strip in a string, you can either connect to a mating connector, or cut and strip the
wires, and connect them to your controlling device. To reuse the rest of the LED strip, check out the LED Strip
pigtail connector to easily connect the cut strips:
Addressable Through-Hole LED
If you require WS2812 LEDs in through-hole form, they are also available as a through-hole package.
LED Strip Pigtail Connector (3-pin)
CAB-14575
