HMS OPERATION – SURVEYING IR ENVIRONMENT / FCU TEST
Check Sensor FOV
Check Sensor Field of
View By Moving FCU
to Confirm Limits
HMS On indicator
Red Glow = ON
Survey
Room
Rotate Sensor
While Seated in
Flying Position
to Check for
Stray IR Light
Occlude Any
Detected IR
Sources
IR and USB indicator
Green = IR Source Detected
Also Flashes when Sending
HID DATA
141 FOV
141 FOV
BAD
Photo Courtesy
mariner3302
FCU In FOV
Green Glow =
FCU Visible
FCU Out Of FOV
No Green Glow =
FCU Not Visible
