SPEKTRUM DX7 • HELICOPTER PROGRAMMING GUIDE SPEKTRUM DX7 • HELICOPTER PROGRAMMING GUIDE
Input Select
The Input Select function is used to select the switch input for the gyro gain and the channel that will operate
the gyro gain.
[INPUT SELECT]
≥AUX2 GEAR
GYRO INH
INCREASE and DECREASE key
Press to enter
INPUT SELECT
Hold while turning on transmitter
To Select the Function for the AUX 2 Channel
Press the DowN and SELECT keys simultaneously, then turn on the transmitter.
Press the UP or DowN key until the INPUT SELECT function appears on screen.
Press the SELECT key until AUX 2 is highlighted.
Press the INCREASE or DECREASE key to select the desired function.
The Auxiliary 2 channel options are
INH:
Inhibit is selected if the gyro function will not be used on the Aux 2 channel.
F.MODE:
In this mode, the AUX 2 channel is controlled by the flight mode switch and three positions are available. Sub
trim and travel adjust are used to set the center and endpoints for each switch position.
AUX 2:
The Auxiliary 2 switch controls the AUX 2 Channel.
GYRO:
The gyro mode is selected if you want to use the Gyro Sensing (see page 96 for more details). Selecting GYRO
under AUX 2 assigns the gyro sensing program to operate use the AUX 2 channel. In this case the gyro gain
must be plugged into the AUX 2 (Channel 7) channel.
Input Select (continued)
[INPUT SELECT]
AUX2 ≥GEAR
INH INH
INCREASE and DECREASE key
Press to enter
INPUT SELECT
Hold while turning on transmitter Press to reset
To Select the Function for the Gear Channel
Press the DowN and SELECT keys simultaneously, then turn on the transmitter.
Press the UP or DowN key until INPUT SELECT appears on screen.
Press the SELECT key until GEAR is highlighted.
Press the INCREASE or DECREASE key to select the desired function.
The gear channel options are
INH:
Inhibit is selected if the gyro function will not be used on the gear channel. Selecting inhibit turns off the gear
channel, allowing it to be used as a slave channel for mixing.
GEAR:
Gear is selected if the gyro gain or retractable gear position is to be selected using the gear switch.
GYRO:
Gyro is selected under gear if you wish to have the Gyro Sensing (page 96) operate using the
gear channel.
AUX 2:
The Auxiliary 2 switch is used to activate the gear channel.
