28
Driveshaft
Installation
Note: Failure to torque strap bolts in the proper sequence may
cause premature bearing failure.
6. Torque strap bolts to specification according to
the chart below.
7. Grease the U-joint and slip member after drive-
shaft installation. Refer to Lubrication section of
this manual. Refer to Dana information bulletin
J3295 for grease specification guidelines.
Bolt Specifications - Quick Disconnect™
Series Thread
Size
Head
Size
Bolt Torque
Nm
Bolt Torque
Lb. Ft.
SPL 55
SPL 70
SPL 90/100
3/8 - 24 3/8"
12 point
61-81 45-60
SPL 140
SPL 170
SPL 250
12mm -
1.25
1/2"
12 point
156-170 115-125
Start Here
Start Here
12
1
2
To Next Page
