Glossary
Glossary
Midship Shaft - A machined element consisting of spline
teeth, a pilot for a center bearing and a piloting hub that
attaches to the tube of a coupling shaft assembly.
Needle Rollers - One of the rolling elements of a bearing cup
assembly.
Outboard Components - Yokes that are not a part of a drive-
shaft, i.e. transmission, axle, transfer case end yokes and/or
companion flanges.
Phase Angle - The relative rotational position of each yoke on
a driveshaft or driveline.
Pressure Relief Hole - A hold in the welch plug of Spicer slip
yokes that allows air to escape from the slip member assem-
bly.
Purge - The act of flushing old grease and contaminants from
universal joint kits and slip member assemblies with fresh
grease.
Quick Disconnect Cross Hole - A semicircular hole located on
the end of each lug ear of some end yoke and flange yoke
designs used to locate a bearing cup assembly.
Retaining Ring - See Snap Ring.
Retaining Ring Groove - See Snap Ring Groove.
Seal Can - A metal "can" that permanently seals the slip mem-
ber on a driveshaft. Usually found on European-style drive-
shaft assemblies.
Seal Guard - A covering member used to protect a bearing
seal on the bearing cup assembly.
Serrated Flange - See T-Flange
Shaft Length - Distance between the outermost universal joint
center to joint center.
Shaft Support Bearing - See Center Bearing
Slinger - A stamped metal or non-metal ring which prevents
the entry of foreign matter into a center bearing, transmission,
axle or transfer case.
Slip - The total permissible length of axial travel.
Slip Yoke - A yoke which accomodates axial movement.
Slip Yoke Plug - See Welch Plug.
Slip Yoke Seal - Pop-on or threaded ring that contains a seal
that protects the slip member assembly from environmental
contaminants and retains lubricant.
Snap Ring - A removable member used as a shoulder to
retain and position a bearing cup assembly in a yoke cross
hole.
Snap Ring Groove - A groove used to locate a snap ring.
Spline - A machined element consisting of integral keys
(spline teeth) or keyways (spaces) equally spaced around a
circle or portion thereof.
Spline Sleeve - A tubular-type, machined element consisting
of internal splines which is attached to a tube or tube yoke in a
driveshaft assembly.
Spring Tab - A patented stamped metal plate that takes the
place of a bearing plate and acts as a structural member by
reducing looseness in a universal joint kit. Found only on
Spicer Life Series driveshaft assemblies.
Stub Shaft - See Tube Shaft.
Tang - A nib of metal found on Quick Disconnect end yoke
and/or flange yoke style cross holes, used to locate a bearing
cup assembly.
T-Flange - A companion flange and flange yoke design which
has a serrated flange face. Found most often in European
applications.
T-Type Flange - See T-Flange.
Thrust Washer - A washer found in the bottom of a bearing
cup assembly that reduces needle roller friction, bearing heat
and guards against end galling on the journal cross trunnions.
Tubing - See Tube.
Tube O.D. (outside diameter) - The outside diameter of a
tube.
Tube Yoke - An inboard yoke with a piloting hub for attach-
ment to a tube or spline sleeve.
Tube Shaft - A machined element consisting of spline teeth
and a piloting hub that attaches to the tube of a driveshaft
assembly.
Trunnion(s) - Any of the four projecting journals of a cross.
