ROOF
11
1. TWO PEOPLE required to lift and rest roof onto hut walls.
2. Attach roof assembly to hut as shown.
Parts Required:
1. TWO PEOPLE required to lift and rest roof onto hut walls
2. Attach roof assembly to hut as shown
#8 x
3
4
" Truss Head Screw
X32
All corners of the hut walls should be inline
with the seam in the roof panel frame when
the roof assembly is resting on the hut
Two people required to lift and place
the roof assembly onto the hut.
The roof will rest on the corners of the hut
303
From inside the hut, locate bracket
against the roof brace and wall brace.
Attach as shown at (4) four locations
(Note: The roof will remain resting on
the four corners)
Two people required to lift and place
HINT - FOR A WATERTIGHT SEAL, USE A
EXTERIOR RATED CAULK ALONG THE
SEAMS IN THE ROOF
%UDFNHW;
To Next Page
