Spinning TRIO - Pedal Installation and Adjustment; Threadless Pedal Installation; Threaded Pedal Installation; Cleat Compatibility Adjustment

INSTALLATION:
THREADLESS
INSTALLATION:
THREADED
TRIO® QR
Before beginning, turn the Spinner®
resistance knob clockwise to lock the flywheel
in place. “Left” and “Right” are determined
from a seated position on the bike.
Before beginning, turn the Spinner®
resistance knob clockwise to lock the flywheel
in place. “Left” and “Right” are determined
from a seated position on the bike.
The pedals come factory set at the lightest release
adjustment setting and can be changed by the user
for a stronger hold if desired.
Install the pedals according to the graphic
below and ensure the pedals are securely
tightened. The recommended torque spec
is 47–57 Nm or 35–40 ft-lbs.
Install the pedals according to the graphic
below and ensure the pedals are securely
tightened. The recommended torque spec
is 35 Nm or 25 ft-lbs.
TRIO® QR
TRIO® QR
TRIO®
TRIO®
TRIO®
RELEASE TENSION
ADJUSTMENT
ADJUST SPD®ADJUST SPD®
ADJUST DELTAADJUST DELTA
SPD® COMPATIBLE
CLEATS IN/OUT
TRIO® QR
TRIO® QR
TRIO® QR
TRIO®
TRIO®
TRIO®
LOOK® DELTA COMPATIBLE
CLEATS IN/OUT
IN
IN
OUT
OUT
IN OUT
PLATFORM INSTALL
AND REMOVAL
PLATFORM INSTALL
AND REMOVAL
IN
OUT
SECURING THE
TOE STRAP
