No. Part Material Quantity Size Sheet
0 Jig Depron 1 300 x 600
1 Frame Plywood 1 3 mm 1
2 Frame Plywood 1 3 mm 1
3 Frame Plywood 1 3 mm 1
4 Frame Plywood 1 3 mm 1
5 Keel Plywood 1 2 mm 2
5.1 Keel reinforcement Plywood 2 2 mm 2
5.2 Keel reinforcement Plywood 2 2 mm 2
6 Keel Mahogany plywood 2 1.5 mm 3
6.1 Keel Mahogany plywood 2 1.5 mm 3
7 Stringer Plywood 2 2 mm 2
8 Hull side Mahogany / obechi 2 1.5 mm 4
9 Aft hull bottom Plywood 1 1 mm 5
10 Half-frame Plywood 1 3 mm 1
11 Forward hull bottom Plywood 1 1 mm 5
12 Stringer Plywood 2 2 mm 2
13 Stringer Plywood 2 2 mm 2
14 Stringer Plywood 2 2 mm 2
15 Stringer Plywood 1 2 mm 2
16 Cockpit side panel Mahogany plywood 2 1.5 mm 3
17 Cockpit front panel Mahogany plywood 1 1.5 mm 3
18 Control stand base plate Plywood 1 3 mm 1
19 Control stand side Plywood 2 3 mm 1
20 Control stand link piece Plywood 1 3 mm 1
21 Control stand servo plate Plywood 1 3 mm 1
22 Steering wheel bush Brass tube 1 3 / 4 Ø x 25 mm 7740/41
23 Instrument panel Mahogany plywood 1 1.5 mm 3
24 Reinforcement Plywood 4 3 mm 1
25 Aft deck panel Mahogany plywood 2 1.5 mm 3
26 Steering wheel core Plywood 1 2 mm 2
27 Steering wheel rim Plywood 2 1 mm 5
28 Return pulley disc Plywood 2 1 mm 5
29 Return pulley core Plywood 2 2 mm 2
30 Return pulley centre Plywood 1 1 mm 5
31 Steering wheel shaft Brass 1 3 Ø x 60 mm 7732/30
31.1 Screw + nut Metal 2+2 M1.4 7772/08+7774/51
32 Coupler + grubscrew Aluminium 1+1 M3 x 3 7492/14+7784/31
33 Servo plate Plywood 1 3 mm 1
33.1 Servo plate doubler Plywood 2 3 mm 1
34 Outer pulley bracket Mahogany plywood 4 1.5 mm 3
35 Pulley bracket core Mahogany plywood 4 1.5 mm 3
36 Ring-screw Metal 2 5463/15
37 Return pulley Metal 4 5228/00
38 Bottle-screw bracket Metal 2 5301/01
39 Transom Mahogany plywood 1 1.5 mm 3
39.1 Transom reinforcement Plywood 1 2 mm 2
40 Motor mount bracket Plywood 4 3 mm 1
41 Motor mount plate Plywood 1 3 mm 1
42 Kneeling board Plywood 2 2 mm 2
43 Self-tapping screw Metal 4 2.2 x 9.5 7766/22
44 Rubbing strake Mahogany plywood 2 1.5 mm 3
45 Covering support Plywood 1 1 mm 5
46 Covering Oratex 1 Oversize
47 Bottle-screw Brass 2 5300/28
48 Locknut Brass 6 M2 7773/02
49 Braided steel wire Steel / plastic 1 1500 mm Overlength
50 Crimp sleeve Brass 2 1.5 / 1.1 Ø x 8 mm Overlength
51 Screw Brass 8 M2 x 6
52 Self-locking nut Steel 4 M2 7774/01
54 Etched parts set Nickel-silver
