Spitznas 2 2406 0010 - Spare Parts Identification

Hyd ra ulic Hammer Drill
2 2406 0010
Ma s ch in e n f a br ik Gmb H
Translation of the original repair
instruction, compiled: 16.05.17
224060010_Inst_en_Version_06.doc
Page
2
of
1
4
Spare Part List
Description: Part and drawing number:
Hydraulic Rotary Hammer Drill 2 2406 0010
Item
Qty. Description Part and drawing no. Remarks
1 Output unit, assy. 2 2426 7000 see extra list
1 Hydraulic motor 2 2406 1000 see extra list
1 Handle, assy. 2 2406 7000
1 Connection lug 2 2406 6040
2 Counter sunk screw 9 1113 3010
1 Socket head screw 9 1110 3120
1 Socket head screw 9 1112 5120
1 Gasket 9 1903 0270 *
1 Second handle, assy. 2 2408 6900 see extra list
1 Cooling pipe 2 2404 9200 see extra list
1 Hydraulic hose set 2 2406 9010
1 Carrying case 5 1212 9000
1 Multi-Oil Spray 9 9902 0120
1 Type label 9 3101 0410
2 Round head grooved pin 9 1628 0040
1 Sign 9 3101 0570
1 Sticker 9 3104 0380
* Wear parts to be stored in case of continuous
use
