PARTS LIST
30
7
25
30
25
16
6
34
34
5
35
22
26
19
22
11
22
25
25
26
10
4
22
22
25
25
19
26
15
21
41
25
18
31
36
8
28
21
22
26
19
24
29
27
13
2426
35
26
15
19
31
38
38
31
37
9
37
32
1
32
16
37
2
37
36
31
25
25
18
24
33
16
25
25
25
25
17
17
17
12
3
38
38
40
25
25
14
10
14
11
39
24
41
16
16
25
PART NO. DESCRIPTION PART NAME QTY
29 M10 Knob 1
30 25*25*T1.5 Square plug 2
31
25 Globose plug 4
32 30*70 Oval plug 2
33 25*18 Cushion pad 1
34 30*70 Cap 2
35 70*65*25 Connecting pipe over 2
36 125L*T3.0 Cover 2
37
75* 23*155L Foam Pads 4
38
75*155L Cover 4
39 600*290*T45 Backrest 1
40 370*270*T45 Seat 1
41
10 Nylon bearing 2
PART NO. DESCRIPTION QTY
1 Front stabilizer 1
2 Front support pipe 1
3 Seat support pipe 1
4 Rear support pipe 1
5 Rear stabilizer 1
6 Backrest adjust pipe 1
7 Backrest Frames 2
8 Long pad tube 1
9 Short pad tube 1
10 Long dumbbell hook 2
11 Short dumbbell hook 2
12 M10*155 Hex head bolt 1
13 M10*90 Hex head bolt 1
14 M8*90 Hex head bolt 2
PART NO. DESCRIPTION QTY
15 M8*82 Hex head bolt 2
16 M8*45 Hex head bolt 5
17 M8*20 Hex head bolt 3
18 M8*15 Hex head bolt 2
19 M8*30 Hex head bolt 4
21 M10 Nylon locknut 2
22 M8 Nylon locknut 7
24 M10 Flat washer 4
25 M8 Flat washer 17
26 M8 Curve washer 8
27 M10 L-bolt 1
28 Wrench 2
Attention: The mechanical symbol for diameter is .
