If for any reason you need to
remove a rod from the mat,
do not twist or rotate the mat
edge as shown. This could
cause serious injury or
damage the trampoline.
Si vous devez désinstaller une
tiges du tapis, ne tordez et ne
tournez pas le bord du tapis.
Cela peut entra ner de graves
blessures ou des dommages
au trampoline.
Lay out the parts as shown.
SCAN HERE
or visit http://springfr.ee/g4-install-ov for a helpful installation overview video.
Black Net Rods + Horizontal Rods
Part Quantity Part Quantity
Mat
White Mat Rods
Net
1
58
1
10 + 2
1
3
D.
Spare Small Bolt & Nut
Spare C-clips
A.
B.
C.
A
C
D
B
To Next Page
