Layout all parts listed as shown.
Part Description
A
B
C
D
E
F
Tablet Holder Rods
Sensor Cables
Tablet Holder
Sensor Cable Tube
Controller
Battery Pack
1
2
1
1
1
1
Part Description
G
H
I
J
K
L
M
Sensor Top Plate
Sensor Mount
Cable Clips
Nut and Hex Key
Large Cable Ties
Small Cable Ties
Spare Small Cable Ties and Cable Clips
4
4
54
1
2
10
8+4
NOTE - TWO people are required for assembly.
NOTE - Installation typically takes ONE hour to complete.
SCAN HERE or visit http://springfr.ee/install-tgoma for a helpful installation video.
TIP - Throughout this manual, certain images contain parts that have been colored orange. This is meant
to bring specific attention to a particular installation step and is not a representation of their actual color.
A
B
C D
E G
H
J
KF
L
I
To Next Page
