Tableros de distribución combinados I-Line™ 80043-808-02 Rev. 02
Anexo 1: Especificaciones—Corriente nominal de cortocircuito adicional 03/2017
42
ESPAÑOL
240/120
3P/4W
42,000
LC 600 A
QO (B) VH 15–70 A 15–125 A 15–100 A
QO (B) GFI 15–30 A 15–60 A 15–30 A
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A — —
QO (B) DF 15–20 A — —
MG QO (B) VH 15–30 A 15–30 A 15–30 A
65,000
LC 400 A
QO (B) 15–30 A 15–30 A —
QO (B) VH 15–30 A 15–125 A 15–100 A
QO (B) GFI 15–30 A 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A — —
QO (B) DF 15–20 A — —
LC 600 A
QO (B) VH 15–30 A 15–125 A 15–150 A
QO (B) GFI — — 15–30 A
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A — —
QO (B) DF 15–20 A — —
DJ 400 A
QO (B) 15–70 A 15–125 A —
QO (B) VH — — 15–150 A
QO (B) H — 15–100 A —
DJ_W
QO (B) 15–70 A 15–150 A —
QO (B)-VH — 110–125 A 15–150 A
QO (B) GFI 15–30 A 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A — —
QO (B) DF 15–20 A — —
DJ, DG, DL
150–600 A
QO (B) EPD — — 15–30 A
EG, FG, KG
QO (B) 15–70 A 15–125 A 15–100 A
QO (B) GFI 15–30 A 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A — —
QO (B) DF 15–20 A — —
Continued on next page
Table 8: Series Connected Breaker Ratings (RMS Symmetrical) (continuación)
Max.
System
Voltage
AC
1, 2
Max.
Short
Circuit
Current
Rating
Square D Brand
Integral or Remote
Main Circuit Breakers
and Remote
Main Fuses
Square D Brand Branch Circuit Breaker
Catalog Designation and Allowable
Ampere Ranges
3, 4, 5, 6
Type 1 Pole 2 Pole 3 Pole
80043-808-01.book Page 42 Wednesday, March 22, 2017 12:31 PM

Square D I-Line Specifications

General

Bus Material	Aluminum or Copper
Voltage Rating	600V AC
Current Rating	Up to 1200A
Enclosure	NEMA 1
Poles	2, 3
Interrupting Rating	200 kA (depending on the specific model and installed breakers)
