© 2013–2017 Schneider Electric Reservados todos los derechos
Tableros de distribución combinados I-Line™ 80043-808-02 Rev. 02
Anexo 1: Especificaciones—Corriente nominal de cortocircuito adicional 03/2017
50
ESPAÑOL
240 3P/3W or
240 1P/2W
(two pole only)
200,000
200 A Max.
Class J or T6
Fuses
QO (B) EPD 15–50 A
QO (B) EPE 15–50 A
400 A Max.
Class T3
Fuses
QO (B) 15–100 A
QO (B) EPD 15–50 A
QO (B) EPE 15–50 A
1
For shown circuit breakers rated less than this maximum voltage, the indicated short circuit current rating also
applies, but at the voltage rating of the circuit breaker.
2
Short circuit tests are conducted at 100–105% of the maximum rated voltage of the panelboard.
3
Suffixes HID, SWD, and SWN may also be applied to the applicable branch circuit breakers shown above.
Suffix SWN may not be applied in combination with LC main breakers.
4
Where QO (B) circuit breakers are shown above, QO (B) H, QO (B) VH, and QH (B) circuit breakers may also
be used.
5
Where QO (B) GFI circuit breakers are shown above, QO (B) EPD and/or QO (B) EPE circuit breakers may
also be used. QO-EPE only comes in 3-pole construction.
6
Where QO (B) AFI circuit breakers are shown above, QO (B) CAFI circuit breakers may also be used.
7
Two-pole CAFI circuit breakers are only 120/240 Vac and may only be used on 120/240 VAC single
phase 3 wire systems.
8
To achieve selective coordination, the rating of the DJ main circuit breaker must be at least two times greater
than the ampere rating of any branch circuit breaker.
Table 8: Series Connected Breaker Ratings (RMS Symmetrical) (continuación)
Max.
System
Voltage
AC
1, 2
Max.
Short
Circuit
Current
Rating
Square D Brand
Integral or Remote
Main Circuit Breakers
and Remote
Main Fuses
Square D Brand Branch Circuit Breaker
Catalog Designation and Allowable
Ampere Ranges
3, 4, 5, 6
Type 1 Pole 2 Pole 3 Pole
80043-808-01.book Page 50 Wednesday, March 22, 2017 12:31 PM
