Panneaux de commutation combinés I-Line
MC
80043-808-02 Rév. 02
Annexe 1 : Spécifications—Valeurs nominales de la section I-Line 03/2017
32
FRANÇAIS
Tableau 6 : Valeurs nominales de fusibles raccordés en série, section I-Line
(RMS symétriques)
Tension ca
maximale
du
système
1
Courant
nominal de
court-circuit
max.
Fusible principal à
distance
Désignation du catalogue des
disjoncteurs de dérivation Square D
(bipolaire ou tripolaire), sauf indication
contraire
A max. Classe
120/240 1Ø
208Y/120
100,000
1200 A L, T (300 V)
QD, QG800 A T (600 V)
600 A J, RK5
240
65,000
1200 A L, T (300 V)
QD800 A T (600 V)
600 A J, RK5
100,000
1200 A L, T (300 V)
QD, QG (2-Pole)800 A T (600 V)
600 A
J, RK5
J, T (600 V) FA, FH, KA, KH, KC, LA, LH, MA, MH, MX, PG
RK5
FH, KA, KH, LA, LH, MA, MH, MX, PG, HD, HG,
HJ, HL, JD, JG, JJ, JL
J HD, HG, HJ, HL, JD, JG, JJ, JL
800 A
T (600 V) FH, KA, KH, LA, LH, MA, MH, MX, PG
T (300 V) PG
L FH, KA, KH, LA, LH, MA, MH, MX, PG
1200 A
L FH, KH, LA, LH, MA, MH, MX, PG
T (600 V) HD, HG, HJ, HL, JD, JG, JJ, JL
1600/2000 A L NA, NC, NX, PJ, PL
4000 A L HD, HG, HJ, HL, JD, JG, JJ, JL
200,000
600 A
J, T (600 V)
FA (3-pole only)
FH, FC, KH, KC, LA, LH, LC, MA, MH, MX, NA,
NC, NX, PG, PJ, PL
RK5
FH, FC, HD, HG, HJ, HL, JD, JG, JJ, JL, KH, KC,
LA, LH, LC, MA, MH, MX, NC, NX, PG,PJ, PL
J HD, HG, HJ, HL, JD, JG, JJ, JL
800 A
T (600 V)
FH, FC, KA, KH, KC, LA, LH, LC, MA, MH, MX,
NA, NC, NX, PG, PJ, PL
T (300 V) PG, PJ, PL
L
FH, FC, KH, KC, LA, LH, LC, MA, MH, MX, NA,
NC, NX, PG, PJ, PL
1200 A
L
FC, KH, KC, LC, MA, MH, MX, NA, NC, NX, PG,
PJ, PL
T (600 V) HD, HG, HJ, HL, JD, JG, JJ, JL
1600/2000 A L NA, NC, NX, PJ, PL
4000 A L HD, HG, HJ, HL, JD, JG, JJ, JL
