Panneaux de commutation combinés I-Line
MC
80043-808-02 Rév. 02
Annexe 1 : Spécifications—Valeurs nominales de la section I-Line 03/2017
36
FRANÇAIS
Tableau 8 : Val. nom. de disjoncteurs raccordés en série (RMS sym.)
Tension ca
max. du
système
1, 2
Courant
nominal
de court-
circuit
max.
Disjoncteurs
principaux intégrés ou
à distance et fusibles
principaux à distance
de la marque Square D
Désignation du catalogue des
disjoncteurs de dérivation de la marque
Square D et gammes d'intensité
admissibles
3, 4, 5, 6
Type 1 pôle 2 pôles 3 pôles
120/240
7
1P/3W
22,000 MG QO (B) 15–30 A — —
25,000 LD, HD, JD
QO (B) 15–70 A 15–125 A —
QO (B) VH 15–70 A 15–125 A —
QO (B) PL 15–30 A 15–60 A —
QO (B) GFI 15–30 A 15–60 A —
QO (B) EPD 15–30 A 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A 15–20 A —
QO (B) DF 15–20 A — —
65,000
HG, JG
QO (B) 15–70 A 15–125 A —
QO (B) VH 15–70 A 15–125 A —
QO (B) PL 15–30 A 15–60 A —
QO (B) GFI 15–30 A 15–60 A —
QO (B) EPD 15–30 A 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A 15–20 A —
QO (B) DF 15–20 A — —
LG
QO (B) 15–70 A 15–125 A —
QO (B) VH 15–70 A 15–125 A —
QO (B) GFI 15–30 A 15–60 A —
QO (B) EPD 15–30 A 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A 15–20 A —
QO (B) DF 15–20 A — —
LJ
QO (B) GFI 15–30 A 40–60 A —
QO (B) EPD 15–30 A 40–60 A —
100,000 HJ, JJ
QO (B) 15–70 A 15–125 A —
QO (B) VH 15–70 A 15–125 A —
QO (B) PL 15–30 A 15–60 A —
QO (B) GFI 15–30 A 15–60 A —
QO (B) EPD 15–30 A 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A 15–20 A —
QO (B) DF 15–20 A — —
80043-808-01.book Page 36 Wednesday, March 22, 2017 12:31 PM

Square D I-Line Specifications

General

Bus Material	Aluminum or Copper
Voltage Rating	600V AC
Current Rating	Up to 1200A
Enclosure	NEMA 1
Poles	2, 3
Interrupting Rating	200 kA (depending on the specific model and installed breakers)
