80043-808-02 Rev. 02 I-Line™ Combo Switchboards
03/2017 Specifications—I-Line Section Ratings
29
ENGLISH
600
18,000
HG, JG FA, HD
2, 3
JG JD
MG, PG, RG HD, JD
MG FA
LG LD 3
LG HD, JD
2, 3
25,000
HJ, JJ FA, HD, HG
JJ JD
PJ, RJ MG
LJ LD, LG 3
LJ JD, JG, HD, HG, MA
2, 3
35,000 LC
FH, HD, HG, HJ, JD, JG, JJ,
LA
50,000
HL, JL FA, HD, HG, HJ
JL JD, JG, JJ
PK HJ, JJ, MJ
LL LD, LG, LJ 3
LL HD, HG, HJ, JD, JG, JJ, MA
2, 3
100,000
FI, KI HD, HG, HJ
KI JD, JG, JJ
HR FA, HD, HG, HJ, HL
JR
FA, HD, HG, HJ, HL,
JD, JG, JJ, JL
KI, LI FH
LI LA
347
18,000
BG6, HG, JG, LG,
MG, PG
BD6 (60 A Max.)
1
25,000
BJ, HJ, JJ, LJ, MJ, PJ BD6, BG6 (60 A Max.)
100,000 HR, JR BD6, BG6, BJ (60 A Max.)
Table 3: Series Connected Circuit Breaker Ratings
(RMS Symmetrical) (continued)
Maximum
System Voltage
AC
2
Maximum
Short Circuit
Current Rating
Square D Brand
Integral or
Remote 2- or 3-
Pole Main Circuit
Breaker
1
Square D Brand Branch
Circuit Breaker
Catalog Designation Poles
