I-Line™ Combo Switchboards 80043-808-02 Rev. 02
Specifications—Lighting Section Ratings 03/2017
40
ENGLISH
208Y/120
3P/4W
100,000 LJ
QO (B) 15–70 A 15–125 A —
QO (B) VH 15–70 A 15–125 A 15–150 A
QO (B) H — 15–100 A —
QO (B) GFI — 15–30 A —
QO (B) EPD — 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A — —
QO (B) DF 15–20 A — —
240/120
3P/4W
22,000 QO (B) VH
QO (B) 15–70 A 15–125 A 15–100 A
QO (B) GFI 15–30 A 15–60 A 15–50 A
QO (B) EPD 15–30 A 15–60 A 15–50 A
QO (B) EPE — — 15–50 A
QO (B) PL 15–30 A 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A — —
QO (B) DF 15–20 A — —
25,000
QD
QO (B) 15–70 A 15–125 A 15–30 A
QO (B) VH — — 35–150 A
QO (B) PL 15–30 A 15–60 A 15–30 A
QO (B) GFI 15–30 A 15–60 A 15–50 A
QO (B) EPD 15–30 A 15–60 A 15–50 A
QO (B) EPE — — 15–50 A
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A — —
QO (B) DF 15–20 A — —
ED, FD
QO (B) 15–70 A 15–125 A 15–100 A
QO (B) GFI 15–30 A 15–60 A 15–50 A
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A — —
QO (B) DF 15–20 A — —
Continued on next page
Table 8: Series Connected Breaker Ratings (RMS Symmetrical) (continued)
Max.
System
Voltage
AC
1, 2
Max.
Short
Circuit
Current
Rating
Square D Brand
Integral or Remote
Main Circuit Breakers
and Remote
Main Fuses
Square D Brand Branch Circuit Breaker
Catalog Designation and Allowable
Ampere Ranges
3, 4, 5, 6
Type 1 Pole 2 Pole 3 Pole
