I-Line™ Combo Switchboards 80043-808-02 Rev. 02
Specifications—Lighting Section Ratings 03/2017
42
ENGLISH
240/120
3P/4W
42,000
LC 600 A
QO (B) VH 15–70 A 15–125 A 15–100 A
QO (B) GFI 15–30 A 15–60 A 15–30 A
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A — —
QO (B) DF 15–20 A — —
MG QO (B) VH 15–30 A 15–30 A 15–30 A
65,000
LC 400 A
QO (B) 15–30 A 15–30 A —
QO (B) VH 15–30 A 15–125 A 15–100 A
QO (B) GFI 15–30 A 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A — —
QO (B) DF 15–20 A — —
LC 600 A
QO (B) VH 15–30 A 15–125 A 15–150 A
QO (B) GFI — — 15–30 A
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A — —
QO (B) DF 15–20 A — —
DJ 400 A
QO (B) 15–70 A 15–125 A —
QO (B) VH — — 15–150 A
QO (B) H — 15–100 A —
DJ_W
QO (B) 15–70 A 15–150 A —
QO (B)-VH — 110–125 A 15–150 A
QO (B) GFI 15–30 A 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A — —
QO (B) DF 15–20 A — —
DJ, DG, DL
150–600 A
QO (B) EPD — — 15–30 A
EG, FG, KG
QO (B) 15–70 A 15–125 A 15–100 A
QO (B) GFI 15–30 A 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A — —
QO (B) DF 15–20 A — —
