Squier Stratocaster Guitar and Controller - Page 4

Back Button
Start Button
Red Button
Green Button
Truss Rod
Adjustment
(side of neck)
4-way Navigation
pad
Squier® by Fender® Stratocaster®
Guitar and Controller
Adjustable Bridge
Contoured Body
Pickguard
Pickup
Rock Band™ 3 MIDI PRO-ADAPTER for PlayStation® 3
Mad Catz® SKU# Sku RB3 97071
Rock Band™ 3 MIDI PRO-ADAPTER for Wii™
Mad Catz® SKU# RB3 96071
Rock Band™ 3 MIDI PRO-ADAPTER for Xbox 360™
Mad Catz® SKU# RB3 98071
Mad Catz® MIDI PRO-Adaptor™
REQUIRED FOR GAMEPLAY
SOLD SEPERATELY BY MAD CATZ®
Battery Compartment
(3 AA batteries included)
On/Off Switch
BACK OF GUITAR
Yellow Button
Blue Button
Indicator LEDs
Volume Knob
5-Pin MIDI connector
(side of body)
Recessed 1/4” Output Jack
Neck and 22-fret
position-sensing
fingerboard
Headstock
Enclosed Tuners
String Mute
Strap Button
Strap Button
