SRC GPX-D150-02-01-SL - Mounting Instructions

Copyright By SRC
Design and Specification are subjected to change
Page 3
Original Screw
Original Screw
Original Screw
Original Screw
Mounting Instructions
Step 1:
Orient the Radiator Guard (1), as shown
above, accessing it close to the Radiator
and slip-in the M6 x 25 Screw (2) , through
the Mounting hole in the Flap on top of
the Guard, and pass it through the flap
(OE) and tighten it.
Step 1:
Take off original screw
