Ss Brewtech Jacketed Unitank - Page 7

TANK FEATURES & ASSEMBLY
ROTATABLE RACKING ARM
1.5” TC BUTTERFLY DUMP VALVE
L - 1.5” TC Buttery Valve
L - 1.5” TC Buttery Valve
H - 1.5” TC Gasket
H - 1.5” TC Gasket
I - 1.5” TC Clamp
P -
DIN Nut Rotatable Racking Arm w/ 1.5” TC Port
I - 1.5” TC Clamp
Q - Elbow
L
L
H
H
I
I
Q
H
I
P
Page 7
