CTYON 2006.03
8510-05
CIRCUIT
3) CIRCUIT DESCRIPTION
(1) TIME LAG POWER WINDOW CONTROL
The power window is turned off when turning the ignition key to “ON” position.
The power window relay is turned “ON” for 30 seconds (T1) when turning the
ignition key to “OFF” position.
However, the power window relay stays on for 30 seconds (T2) when the ignition key is
turned to “OFF” position while the door is opened.
The power window relay is turned “ON” again for 30 seconds (T2) just for once
when opening the door during its extended operation period of 30 seconds (T1).
The power window relay is turned “OFF” when closing the door during its
extended operation period of 30 seconds (T2).
-
-
-
-
To Next Page
