CIRCUIT
H. WATER TEMPERATURE SENSOR
The water temperature sensor is installed on the top of heater unit.
It detects the inside temperature of waterand transmits the voltage value that is changed
according to resistance value (NTC) to FATC controller.
Inspection
▶
Remove the water temperature sensor and measure the resistance between
terminals on the sensorconnector. (standard: approx. 25°C, 2.2 kW)In addition,
if the resistance is extremely high or, replace the sensor.
If the measured value is out of the specified range, replace the water temperature
sensor. If the measured value is within the specified range, check as below.
Turn the ignition switch to ON position and measure the voltage to wate
r
temperature sensor from theFATC controller connector. (standard: approx. 2 V at
25°C)
If the voltage value cannot be measured, check the circuit for open. If the measured
value is within thespecified range, replace the FATC controller.
-
-
-
-
I. POWER TRANSISTOR
The power transistor controls the fan speed.
It controls the blower motor operating speed without stages bychanging the current value to
the base of power transistor when receiving the fan control signal from FATC.
J. INTAKE SENSOR
The intake sensor outputs the compressor ON or OFF signal to ECU to prevent evaporato
r
from freezing.
Thesensing part of the thermistor is the evaporator fin contact type.
If the air conditioner does not turn on, check as below.▷
Remove the intake sensor and measure the voltage between terminal No. 1 and 2 on
the connector.
Check whether the output voltages (ON: approx. 12 V, off: 0 V).
If the voltage value is out of the specified value, replace the intake sensor. If the
circuit is in normalcondition, check as below.
Turn the ignition switch to ON position and turn on the air conditioner by pressing the
A/C button.
Andmeasure the voltage between terminal A12 and A11 on the FATC controlle
r
connector. (standard: approx.12 V)
If the voltage value cannot be measured, check the circuit for open. If the measured
value is within thespecified range, replace the FATC controller.
-
-
-
-
-
K. VEHICLE SPEED CALIBRATION
On the Ambient or the 1/3 Ambient and the blower AUTO, the blower decreases the voltage
with the vehiclespeed 100 km/h such as 1.5 V for the Ambient, 1.0 V for the 1/3
A
mbient.But
it is the exception for the blower max.
L. WIPER CALIBRATION CONTROL
It is possible to generate the frost on the windshield in the rainy days. At this time, FATC
controller allows themode to change the AUTO defroster mode.
Operation Condition: When the passenger operates the wiper on AUTO mode, the
system controls thewiper on the A/C AUTO mode after sending the wiper signal and
controlling the delay for 1 minutes.
-
