SSANGYONG KYRON 2006 User Manual

SERVICE AND MAINTENANCE
13-32
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
DRIVE BELT
Gasoline Engine
The engine could inadvertently start while checking the belt and
cause moving parts to crush or cut. Remove key from ignition
switch.
WARNING
You do not need extra tension adjustment, but check belt
for wear or tension by pushing the belt and replace if
necessary.
Belt replacement: Gasoline Engine
Install a device onto the tension adjuster and rotate clock-
wise to release the tension and take off the belt.
TRANSFER CASE OIL
Service Interval, Specification and Capacity
Inspect every 15,000 km
Change every 60,000 km
(frequent check of oil leak)
ATF DEXRON
®
III
Direct Injection
Diesel Engine,
Gasoline Engine
Part time
AWD
1.4
1.1
Service
interval
Specification
Capacity
13-Service and Maintenance.p65 2006-05-17, ¿ÀÈÄ 1:00Page 32 Adobe PageMaker 6.5K/Win
