0-60
REXTON 2007.09
8710-02
CIRCUIT
Front/Center Room Lamp Control
▶
When the door (Driver’s/Passenger’s) is opened, the front room lamp comes on.
The room lamp stays on for 2 seconds and then dims out through 3 seconds when
closing the opened door.
The dimming operation must have greater than 32 steps per one second.
The room lamp output should stop immediately after turning on the ignition key during
the dimming operation.
The front room lamp comes on for 30 seconds when receiving the unlock signal from
the remote control key while the doors are closed.
The front room lamp and the center room lamp output period is extended by 30
seconds when receiving the unlock signal from the remote control key again during
output. (The lamp stays on when unlocked by the remote control key.)
When a door is opened during its extended period, the lamp stays on. If closed,
operates as in step 2.
The room lamp output stops immediately after receiving the lock signal from
driver’s/passenger’s door lock switches while the driver’s and passenger’s doors
are closed or entering into the anti-theft mode by pushing LOCK button on the remote
control key.
The front room lamp comes on when opening the driver’s door or
assenger’s
door and goes off when closing the opened door while the ignition key is in ON
position.
-
-
-
-
-
-
-
-
-
Tail Lamp Auto Cut (Battery Saver)
▶
The tail lamp is turned on or off according to the operations of the tail lamp switch.
The tail lamp relay is turned off (auto cut) when opening and closing the driver’s
door after removing the ignition key without turning off the tail lamp.
The tail lamp relay is turned on when inserting the ignition key into the ignition switch.
The tail lamp relay is not turned off automatically (auto cut) when opening and closing
the driver’s door while the ignition is removed and the tail lamp is turned on.
-
-
-
-
Windshield heated glass (deicer) switch
▶
The front defogger output is “ON” when turning “ON” the front defogger
(heated glass) switch while the ignition switch is “ON” (with engine running).
The output stops when turning on the front defogger (heated glass) switch again
during its operation.
The output is “ON” only for 6 minutes when turning “ON” the front defogger
(heated glass) switch within 10 minutes after completion of output for 12 minutes.
This can be done only once.
The output is “OFF” when the ignition switch is “OFF”.
-
-
-
-
Ignition Key Hole Illumination
▶
The ignition key hole illumination comes on when opening the driver’s door or
passenger’s door when the ignition key is removed.
The ignition key hole illumination stays on for 10 seconds when closing the door afte
step 1.
The output stops when the ignition key is turned to “ON” position.
The output stops when receiving the lock signal from the remote control key (unde
anti-theft mode).
-
-
-
-
Rear Defogger Timer
▶
The rear defogger output is “ON” when turning “ON” the rear defogger switch
while the IGN 2 switch is “ON” (with engine running).
The output is “OFF” when turning “ON” the rear defogger switch again during
output.
The output is “ON” only for 6 minutes when turning “ON” the rear defogger
switch within 10 minutes after completion of output for 12 minutes. This can be done
only once.
The output is “OFF” when the IGN 2 switch is “OFF”.
-
-
-
-
Door Lock/Unlock Control by Door Lock Switch
▶
The door lock system outputs “LOCK” signal for 0.5 seconds when positioning
the driver’s or passenger’s door lock switch to the lock position.
The door lock system outputs “UNLOCK” signal for 0.5 seconds when
positioning the driver’s or passenger’s door lock switch to the unlock position.
The door lock system outputs “LOCK” signal for 0.5 seconds when switching
from LOCK to UNLOCK by the driver’s or passenger’s door key cylinder.
The door lock system outputs “UNLOCK” signal for 0.5 seconds when switching
from UNLOCK to LOCK by the driver’s or passenger’s door key cylinder.
The alarm will not be activated when switched to UNLOCK by driver’s or
passenger’s door key cylinder switch in theft deterrent mode.
It does not occur abnormal operation when reconnecting the battery afte
disconnecting the battery cable.
All door lock signals are “UNLOCK” for 0.5 seconds just for once when receiving
the “LOCK” signal within 0.5 seconds after closing the driver’s or
assenger’s
door while the ignition key is removed.
-
-
-
-
-
-
-
Door Lock/Unlock by Central Door Lock Switch
▶
The door lock system outputs “LOCK/UNLOCK” signal for 0.5 seconds when
operating the central door lock switch. (However, if the door lock switch (front doors)
is at LOCK position, the system outputs UNLOCK signal, and vice versa.)
The “LOCK” or “UNLOCK” inputs from the central door lock switch in anti-theft
mode are ignored
-
-
The overhead console lamp (front room lamp) comes on when opening the
door(driver’s/passenger’s) while the door coupled front rooom lamp switch is at the
coupled operating position and the key reminder switch is “OFF”.
