Control elements
and connections
1. Antenna The antenna is fixed to the housing, do not try to
unscrew it!
2. PTT key: Transmission key
3. LC display
4. UP/DOWN keys: Stepping forward through the individual menu
settings.
5. Speaker
6. Microphone
7. Menu key: Switching over to the menu.
8. Call key: Sending out a call tone.
9. MIC/SPK socket + charging socket
10. On/off switch and volume controller
On: turn the controller clockwise, off: turn the controller counter
clockwise; if the radio set is on: volume control.
