Assembly Instructions
Step 1
Assembly
a: Insert 4 x camlock
bolt
a
into top
A
.
b: Attach 2 x rail
C
onto
1 x side
B
using 2 x
screw
b
for each.
c: Slide base
D
into
the assembled frame as
shown.
d: Attach 1 x side
B
onto 2 x rail
C
using 4 x
screw
b
.
e: Attach top
A
as shown. Insert 4 x
camlock nuts
c
and
rotate each clockwise for
about 1/4 to 1/2 a turn or
until the nut “connects”
with the bolt and is
secure.
Assembly is complete.
c:
b:
d:
e:
A
a
a
a
a
a:
B
b
B
A
c
C
c
If you need any help or have damaged or missing parts, email techstyle.spares@stadiumcp.co.uk
