Model 700 / 710 / 720 / 730 with Manual Brush & Pad Turret
1-phase 3-phase
Volts 230V 400V
Amps 25 amps 9 amps
Hz 50Hz 50Hz
Model 700 / 710 / 720 / 730 with Electrical Brush & Pad Turret
1-phase 3-phase
Volts 230V 400V
Amps 25 amps 9 amps
Hz 50Hz 50Hz
External Electrical Conductors are colour-coded as follows: -
1-phase 3-phase
Earth Green/Yellow Earth Green/Yellow
Neutral Light Blue Neutral Light Blue
Live Brown Live Brown
Live Black
Live Grey
(Pre - 2008) External Electrical Conductors are colour-coded as follows: -
1-phase 3-phase
Earth Green/Yellow Earth Green/Yellow
Neutral Light Blue Neutral Light Blue
Live Brown Live Red
Live Yellow
Live Blue
Internal Electrical Conductors are colour-coded as follows: -
Earth Green/Yellow
Neutral Light Blue
Live Power Circuit Black
Live Control Circuit Red
For 3-phase machines only, check for correct mains phase connection by
testing the Naumkeag. This should run clockwise when viewed from below.
6
