4
ILLUSTRATION 2
ILLUSTRATION 3
Unit is
Calibrating
Calibration
complete
Ready to scan
Live Wire
Indicator
Graphic
Low Battery
Indicator
A = Wood or metal stud depth detection up to 1/2”
B = Wood or metal stud depth detection up to 1”
C = Wood or metal stud depth detection up to 1-1/2”
CALIBRATING
READY
A B C
38mm
