54
DIGITAL LCD SCREEN / PANTALLA DEL LCD DIGITAL
BATTERY STATUS ICON
ICONO DE ESTADO DE LA
BATERÍA
DIGITAL DISPLAY (VARIES BY FUNCTION)
INDICADOR DIGITAL (VARÍA DEPENDIENDO
DE LA FUNCIÓN)
ALARM ICON
ICONO DE ALARMA
ARROW ICONS
ICONOS DE FLECHA
CLAMP ICONS
ICONOS DE PINZA
BATTERY VOLTAGE INDICATOR
INDICADOR DEL VOLTAJE DE
LA BATERÍA
COMPRESSOR PRESSURE
INDICATOR
INDICADOR DE PRESIÓN DEL
COMPRESOR
USB ICON
ICONO DE USB
COMPRESSOR ICON
ICONO DEL COMPRESOR
JUMP STARTER ICON
ICONO DEL PUENTE AUXILIAR DE ARRANQUE
FAULT ICON
ICONO DEL FALLA
SAFETY GUIDELINES /
DEFINITIONS
DANGER: Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided,
may result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.
Used without the word, indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not
avoided, may result in property damage.
RISK OF UNSAFE OPERATION. When using tools or equipment, basic
safety precautions should always be followed to reduce the risk of personal injury.
Improper operation, maintenance or modification of tools or equipment could
result in serious injury and property damage. There are certain applications for
which tools and equipment are designed. Manufacturer strongly recommends that
this product NOT be modified and/or used for any application other than for which
it was designed. Read and understand all warnings and operating instructions
before using any tool or equipment.
READ ALL
INSTRUCTIONS
WARNING: Read and understand this instruction manual before
using this unit. Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury.
IMPORTANT SAFETY
INSTRUCTIONS
WARNING: FAILURE TO FOLLOW THE FOLLOWING WARNINGS AND
INSTRUCTIONS MAY RESULT IN ELECTRIC SHOCK, FIRE AND/OR SERIOUS
INJURY.
GENERAL SAFETY WARNINGS AND INSTRUCTIONS
• This unit was designed for household use only.
WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, BURST
HAZARD, OR INJURY TO PERSONS OR PROPERTY:
• Avoid dangerous environments. Don’t use appliances in damp or wet locations.
Don’t use appliances in the rain.
• Keep children away. All visitors should be kept at a distance from work area.
• Dress properly. Do not wear loose clothing or jewelry. They can be caught in
moving parts. Rubber gloves and substantial, non-skid footwear are recommended
when working outdoors. Wear protective hair covering to contain long hair.
• Store idle appliance indoors. When not in use, appliances should be stored
indoors in dry, and high or locked-up place – out of reach of children.
• Don’t abuse cord. Never carry appliance by cord or yank it to disconnect from
receptacle. Keep cord from heat, oil, and sharp edges.
• Disconnect appliances. Disconnect the appliance from the power supply when
not in use, before servicing, and when changing accessories.
• Ground Fault Circuit Interrupter (GFCI) protection should be provided on
the circuits or outlets to be used. Receptacles are available having built in GFCI
protection and may be used for this measure of safety.
• Use of accessories and attachments. The use of any accessory or attachment
not recommended for use with this appliance could be hazardous. Refer to the
accessory section of this manual for further details.
• Stay alert. Use common sense. Do not operate appliance when you are tired or
impaired.
• Check for damaged parts. Any part that is damaged should be replaced by the
manufacturer before further use. Contact the manufacturer at 1-877-571-2391 for
more information.
• Do not operate this appliance near flammable liquids or in gaseous or
explosive atmospheres. Motors in these tools normally spark, and the sparks
might ignite fumes.
• Never submerge this unit in water; do not expose it to rain, snow or use
when wet.
• To reduce risk of electric shock, disconnect the unit from any power source
before attempting maintenance or cleaning. Turning off controls without
disconnecting will not reduce this risk.
• This equipment employs parts (switches, relays, etc.) that produce arcs or
sparks. Therefore, if used in a garage or enclosed area, the unit MUST be placed
not less than 18 inches above the floor.
• Do not use this unit to operate appliances that need more than 5 amps to
operate from the 12 volt DC accessory outlet.
• Do not insert foreign objects into the USB port, the 12 volt DC accessory
outlet or the 120 volt AC outlets.
SPECIFIC SAFETY INSTRUCTIONS FOR CHARGING THIS UNIT
• IMPORTANT: This unit is delivered in a partially charged state. Fully charge unit
with a household extension cord for a full 40 hours or until the battery status icon
shows 4 solid bars before using for the first time. You cannot overcharge the unit
using the AC charging method.
• To recharge this unit, use only the built-in AC charger with an AC extension cord
(not included).
• All functions should be turned off when the unit is charging or not in use. Make
sure all functions are turned off before connection to a power source or load.
Extension Cords
WARNING: Use of improper extension cord could result in a risk of fire
and electric shock. When using an extension cord, make sure that the pins of the
extension cord are the same number, size and shape as those in the charger; and
be sure to use one heavy enough to carry the current your product will draw. An
undersized cord will cause a drop in line voltage resulting in loss of power and
overheating. The following table shows the correct size to use depending on cord
length and nameplate ampere rating. If in doubt, use the next heavier gauge. The
smaller the gauge number, the heavier the cord.
MINIMUM GAUGE FOR CORD SETS
Volts Total Length of Cord in Feet
120V 0-25 26-50 51-100 101-150
(0-7.6m) (7.6-15.2m) (15.2-30.4m) (30.4-45.7m)
240V 0-50 51-100 101-200 201-300
(0-15.2m) (15.2-30.4m) (30.4-60.9m) (60.9-91.4m)
Ampere Rating Extension Cord Length
More Not more
0’-25’ 26’-50’ 51’-100’ 101’-150’
Than Than American Wire Gauge (AWG)
0 - 6 18 16 16 14
6 - 10 18 16 14 12
10 - 12 16 16 14 12
12 - 16 14 12 Not Recommended
When an extension cord is used, make sure that:
a) the pins of extension cord are the same number, size and shape as those in
the charger,
b) the extension cord is properly wired and in good electrical condition,
c) the wire size is large enough for the AC rating of the charger.
CAUTION – TO REDUCE THE RISK OF INJURY OR PROPERTY DAMAGE:
Pull the extension cord by the plug rather than the cord when disconnecting from
the built-in 120V AC Charger or the AC outlet.
SPECIFIC SAFETY INSTRUCTIONS FOR JUMP STARTERS
WARNING: BURST HAZARD
Do not use the unit for charging dry-cell batteries that are commonly used with
home appliances. These batteries may burst and cause injury to persons and
damage property. Use the unit for charging/boosting a lead-acid battery only. It is
not intended to supply power to a low-voltage electrical system other than in a
starter-motor application.
• Use of an attachment not supplied, recommended or sold by manufacturer
specifically for use with this unit may result in a risk of electrical shock and injury
to persons.
WARNING: RISK OF EXPLOSIVE GASES
• Working in the vicinity of a lead acid battery is dangerous. Batteries generate
explosive gases during normal battery operation. For this reason, it is of the
PPRH7DS _Type2_ManualENSP_071921.indd 4-5PPRH7DS _Type2_ManualENSP_071921.indd 4-5 7/19/2021 11:10:59 AM7/19/2021 11:10:59 AM
