Stanton C.501 - Control Unit and LCD Features; Control Unit Description; LCD Display Indicators

4
MAIN FEATURES
CONTROL UNIT
19 18
1 2 13 16
14
8
15
11 9
67
5
3 12
10 4
17
(1) OP/CL
(2) TIME
(3) LCD
(4) RELAY
(5) PITCH -
(6) PITCH +
(7) PITCH LOCK
(8) Pitch Slider
(9) PLAY/PAUSE
(10)SGL/CTN
(11)CUE
(12)+10/-10.
(13)
(14)
(15)
(16)
(17)PITCH RANGE
(18)CONTROL CONNECTOR
(19)FADER START SOCKETS
LCD
20 21 22 23 282724 25 26
(20)~(23) TRACK,MINUTE,SECOND and FRAME
Displays
(24) BAR Indicators
(25) REMAIN Indicator
(26) TOTAL Indicator
(27) SINGLE Indicator
(28) PITCH DISPLAY
